MSP11
TABLE OF CONTENTS
Front Panel Features
Rear Panel Features
Setup
Logic Inputs
RS-232 Control
Specifications & Block Diagram
Warranty
pg. 2
pg. 3
pgs. 4~11
pgs. 12 & 13
pgs. 14 & 15
pg. 16
INTRODUCTION
The MSP11 Multi-function DSP System Processor combines gain
management, equalization, & delay, all in a convenient and affordable single
rack-space package. This DSP-based unit includes leveling, compression,
limiting, & soft-gating gain functions, as well as a combination of 1/3-octave &
parametric equalization functions, with additional high-pass & low-pass filters,
and it provides calculation for proper distance/delay settings. The MSP11 is
covered by a five-year warranty.
MSP11 features include:
♦ 24-bit Digital Signal Processing (DSP) with 48kHz sampling
♦ single-channel gain management, equalization, & delay
♦ leveling, compression, limiting, & soft-gating gain functions
♦ combined 1/3-octave & parametric equalization (34 bands)
♦ high-pass & low-pass filters with variable frequency & slope
♦ broad delay range useful for room delay or driver alignment
♦ delay includes distance calculations to insure proper settings
♦ balanced inputs & outputs on plug-in barrier strip connectors
♦ no manual controls on chassis, to help prevent tampering
♦ controls & indicators provided by software graphic interface
♦ Windows
®
95/98/NT/2000/XP software & cable included
♦ non-volatile memory presets store/recall processor settings
♦ remote control via RS-232 & programmable logic inputs
♦ incorporates AES recommended grounding practices
♦
marked and UL / C-UL listed power source
♦ covered by Biamp Systems' five-year warranty
