To attach the sorter run on to an end bin destination:
l Line up the two hooks on the end of the sorter run with the gaps either side of the roller and
simply hook the sorter run on,
l Ensure that the sorter run is flat to the device (so items cannot get caught in any gaps) and
that they are level with the other sorter runs on the system.
To attach the blanking corners (without emergency stop buttons):
l Ensure that the sorter runs either side are in place,
l Line the blanking corner up with both sides,
l Screw the blanking corner to each sorter run, using the holes highlighted in the image above.
