2.2.8 Attaching the emergency stop buttons
The emergency buttons are not attached to the flex AMH™ on delivery.
To attach a corner with an emergency button on it:
l Ensure that the sorter runs either side are in place,
l Run the wiring for the Emergency Stop button through the cable access hole on the side
sorter run,
l Line the Emergency button corner up with both sides,
l Screw the corner to each sorter run, using the holes highlighted in the image above,
