119293 6-9 REV E
8. Re-tension the deck drive belt by pulling on the deck
belt idler spring and hooking it in the spring mount on
the deck.
NOTE: On 36” decks a tension spring hook (Excel part
number 604462) can be used to connect the tension
idler spring to the spring mount.
9. Re-install the deck covers. Figure 6-19 & Figure 6-20
10. Re-attach the negative battery cable.
Never operate the mower without the deck covers in
place.
A. Deck drive belt B. Electric clutch pulley
Figure 6-22
