Big Dog ALPHA - Electrical Schematic - Kohler

119293 7-3 REV E
Electrical Schematic — Kohler
SWITCH
IGNITION
B
G
R
K
S
START
KILL
RELAY
CLUTCH
SWITCH
CLUTCH
ENGINE
BATTERY
NEUTRAL SWITCH
NEUTRAL SWITCH
SEAT SWITCH
STARTER
SOLENOID
RED(14)
BRN(18)
ORG/RED(16)
TAN(18)
TAN/RED(18)
TAN/RED(18)
TAN/RED(18)
TAN/RED(18)
BLK(6)
RED(6)
RED(6)
PUR(14)
BLK(18)
BLK(18)
BLK(18)
MASTER FUSE
15A
PUR(14)
TAN(18)
RELAY
RED(14)
BLK(16)
BLACK (14)
ORG (14)
HOUR
METER
BLK(18)
PUR(18)
-
+
BRN(18)
RED/BLK (18)
BLK(18)
GROUND
SPLICE
ORG(18)
ORG(18) ORG(16)
ORG(16)
BLK(18)
RED/BLK(18)
