Hose label colors:
• Red - oil from pump.
• Blue - oil to tank.
• Yellow - Brake
Marking for hydraulic hoses
Table 4.
No.
Color mark
Function
1
Yellow
Brake
10
Red
Tipping cyl. ( up )
11
Blue
Tipping cyl. ( down )
12
Red
Tower ( front )
13
Blue
Tower ( back )
14
Red
Telescope ( in )
15
Blue
Telescope ( out )
16
Red
Frame-lock for tipping
17
Blue
Frame-lock for hooking
18
Red
Bogie-block ( on )
19
Blue
Bogie-block ( off )
20
Red
Bogie-lift ( on )
21
Blue
Bogie-lift ( off )
22
Red
Extra port ( a )
23
Blue
Extra port ( b )
24
Red
Rear tailgate ( a )
25
Blue
Rear tailgate ( b )
26
Red
Steering control ( p )
27
Blue
Steering control ( t )
28
Blue
Straight steering control (t)
