3.4. CHANGING OPERATING FUNCTION
Figure 21 shows the hydraulic changing drive between the operating functions.
The changing unit is located on the middle of the back frame.
Figure 33. Changing operating function
Locking pin
Tipping position
Hooking position
Hydraulic cylinder
Back frame
Hook frame
