3.5. ELECTRICAL SYSTEM
The trailer is manufactured with 12V electrical system. Configuration depends
of options, example reversing light, border light or additional cable connector.
Note! For complete connection schedule see the following page
Figure 34. Electrical diagram
Electrical components.
Table 5.
Pos.
Art. No.
Title
1
920765
Rear light
1
920766
Rear light with reversing light - special
2
920770
Border light 111x40 (orange) - special
3
920715
Cable terminal
4
920695
Cable Connector 7 pools (male)
5
920180
Cable Connector 7 pools (female) -special
7 pool connection to
pulling vehicle
