1.2. TECHNICAL SPECIFICATIONS
Technical specifications.
Table 1.
Hooklift trailer 20-24
Frame:Hollow sections
300*100
Bogie:Pendulum
Axel distance 1470 mm
Hubs:
110*110, 10 bolts
Wheels:
600/50-22,5
Brake: Hydraulic drum *Depending on market
400*120 on 4 wheels
Towing eyelet:
Type for hitch hook
Support leg: Manual
yes
Light system:12 volt
yes
Tractor hydraulic: *For brakes
3 double, *1 single action
Oil volume: With system filled
23 L
Oil volume cylinders:
Press 89 L, draw 66 L
Oil flow:
60 – 120 L/min
Hydraulic pressure:
22 Mpa
Tipp angle:
50 degrees
Chassi weight (±1%): Standard equipped
4300 kg
Chassi length (±50mm):
7925 mm
Distance eyelet to centred bogie (±20mm):
6270 mm
Distance eyelet to ground surface:
475
Height at skid surface:
1240 mm excluding the hook frame
Wide over tyres (±30mm):
2660 mm
Container length:
5500-6500 mm
Total weight (±1%):
24300 kg
Max load including container (±1%):
20000 kg
Max hooking load including container (±1%):
20000kg
Pressure on eyelet: depending of lenght of container and load
2500 –4500 kg
Max speed:
40 km/h
