BIGREP ONE GENERATION 3 - IV-H Basic Function Test

IV. Setup BigRep
IV-H Basic Function Test
* 2016-04-07
Main switch & Security Stops
1. Check main switch
2. Check emergency button
3. Check both emergency bumper
Check for Updates
Connect the printer with the Internet (RJ45).
1. Select ‚Turn o Printer‘ and select ‚Exit UI‘ This will return you to Linux OS
screen
2. Click the bottom le corner (run) and select ‚accessories‘, then ‚LX Terminal‘.
3. This will give you ‚Terminal (text command line) control of the machine
4. To VIEW the current version, type sudo apt-get update (checks availabili-
ty, password required) and apt-cache policy bigrep-one
You should see info like:
Installed: 0.5.X
Candidate: 0.5.X
5. To update soware type in update_one (password required)
6. Turn on and o machine twice!
Current version: Updated Version:
Touch Screen
Calibrate if necessary: Go to Terminal Tools / screen calibration in Linux
Check if screen is reacting
End Stop Functionality
Drive manually over the max position of each axis and check if end stops are trig-
gered. For example: X MAX --> G1 X1100 F5000. Note position:
X
min
: X
max
: Y
min
: Y
max
: Z
min
: Z
max
:
Important:
Do not use more than F5000 (speed) - otherwise you would drive into X Motor
Test Heating Units
1. Bed: Heat up to 60 °, check time
2. Heat T0/T1 to 220° and check tolerance
Bed should be heated by 2°/min. Tolerance T0/T1 +/- 3° up and down
IV-H 1/2
