# x offset from origin in ### mm 80.75 mm distance nozzle +
6mm extruder.t1.offset ###
extruder.T0.y_offset 6 #
y offset from origin in mm
extruder.T0.z_offset 0 #
z offset from origin in mm
# firmware retract settings when using G10/G11, these are the
defaults if not defined, must be defined for each extruder if
not using the defaults
#extruder.T0.retract_length 3 #
retract length in mm
#extruder.T0.retract_feedrate 45 #
retract feedrate in mm/sec
#extruder.T0.retract_recover_length 0 #
additional length for recover
#extruder.T0.retract_recover_feedrate 8 #
recover feedrate in mm/sec (should be less than retract
feedrate)
#extruder.T0.retract_zlift_length 0 #
zlift on retract in mm, 0 disables
#extruder.T0.retract_zlift_feedrate 6000 #
zlift feedrate in mm/min (Note mm/min NOT mm/sec)
delta_current 1.5 #
First extruder stepper motor current
# Second extruder module configuration
extruder.T1.enable true #
Whether to activate the extruder module at all. All
configuration is ignored if false
extruder.T1.steps_per_mm 171 #
Steps per mm for extruder stepper
extruder.T1.default_feed_rate 600 #
Default rate ( mm/minute ) for moves where only the extruder
moves
extruder.T1.acceleration 500 #
Acceleration for the stepper motor, as of 0.6, arbitrary ratio
extruder.T1.max_speed 50 #
mm/s
extruder.T1.step_pin 1.16 #
Pin for extruder step signal
extruder.T1.dir_pin 1.17 #
Pin for extruder dir signal
extruder.T1.en_pin 0.19 #
Pin for extruder enable signal
extruder.T1.mv_pin 0.5! #
Pin for extruder moving signal, for multi extruder usage
extruder.T1.fan_en_pin 0.1 #
Pin for associated fan to cool the filament
extruder.T1.x_offset 6 # x
offset from origin in mm ## if T1 is activated and G1 XO was
run the result is 6mm distance to the endstop ##
extruder.T1.y_offset 6 # y
offset from origin in mm
extruder.T1.z_offset 0 #
z offset from origin in mm
epsilon_current 1.5 #
Second extruder stepper motor current
extruder_lift_enable
