# mm/min
# Stepper module pins ( ports, and pin numbers, appending "!"
to the number will invert a pin )
alpha_step_pin 1.0
# Pin for alpha stepper step signal
alpha_dir_pin 1.1 #
Pin for alpha stepper direction
alpha_en_pin 0.15
# Pin for alpha enable pin
alpha_current 1.5
# X stepper motor current
alpha_max_rate 100000.0
# mm/min
beta_step_pin 1.4
# Pin for beta stepper step signal
beta_dir_pin 1.8 #
Pin for beta stepper direction
beta_en_pin 0.16
# Pin for beta enable
beta_current 1.5
# Y stepper motor current
beta_max_rate 35000.0
# mm/min
gamma_step_pin 1.9
# Pin for gamma stepper step sign
gamma_dir_pin 1.10 #
Pin for gamma stepper direction
gamma_en_pin 0.17
# Pin for gamma enable
gamma_current 1.5
# Z stepper motor current
gamma_max_rate 300.0
# mm/min
# Serial communications configuration ( baud rate default to
9600 if undefined )
uart0.baud_rate 115200
# Baud rate for the default hardware serial port
second_usb_serial_enable false
# This enables a second usb serial port (to have both
pronterface
# and a terminal connected)
leds_disable false
# disable using leds after config loaded
play_led_disable false
# disable the play led
msd_disable false
# disable the MSD (USB SDCARD) when set to true (needs special
binary)
dfu_enable false
# for linux developers, set to true to enable DFU
# Extruder module configuration
extruder.T0.enable true #
Whether to activate the extruder module at all. All
configuration is ignored if false
extruder.T0.steps_per_mm 171 #
Steps per mm for extruder stepper
extruder.T0.default_feed_rate 600 #
Default rate ( mm/minute ) for moves where only the extruder
moves
extruder.T0.acceleration 500 #
Acceleration for the stepper motor, as of 0.6, arbitrary ratio
extruder.T0.max_speed 50 #
mm/s
extruder.T0.step_pin 1.14 #
Pin for extruder step signal
extruder.T0.dir_pin 1.15 #
Pin for extruder dir signal
extruder.T0.en_pin 0.18 #
Pin for extruder enable signal
