Page #2 background image
Shenzhen BIGTREE technology co., LTD.
BIG TREE TECH
Parameter description
power tube built-in drive current 1.2A ,peak current 2A
256 microsteps per fullstep
interpolation from lower input resolutions
stealthChop2 - for quiet positioning
spreadCycle - for high speed and high dynamics
Low RDSon LS 280mΩ & HS 290mΩ (typ. at 25°C)
Voltage Range 12V/24VDC
Single Wire UART for advanced configuration options
Integrated Pulse Generator for standalone motion
