Billy Goat BC2600 - BC 2600 Series Specifications; Sound Data and Levels; Vibration Data and Measurements

Part No 501505 3 F041513A
BC2600 Hydro Series Brush Cutter Owner’s Manual
BC 2600 SERIES SPECIFICATIONS
BC2600ICH
BC2600HH
BC2600HEBH
Engine Type
Briggs and
Stratton
Honda GX390
Honda Electric
Model Number
219972 0151 F!
GX390UT2 DABG
V390UTDE33
Displacement
344 cc
390 cc
390 cc
Fuel Capacity
3.0 qt (2.80 L)
3.0 qt (2.80 L)
2.3 qt (2.18L)
Oil Capacity
1.5 qt (1.4L)
1.5 qt (1.4L)
1.2 qt (1.13L)
Unit Weight
325 lb (147.4 kg)
325 lb (147.4 kg)
335 lb (152 kg)
Overall Length
72 in (1.83 m)
Overall Width
31 in (0.78 m)
Overall Height
48 in (1.21 m)
Maximum Operating
Slope
15
o
20
o
20
o
SOUND DATA
SOUND LEVEL 91.6 Dba at Operator’s position
Sound tests were conducted in accordance with 2000/14/EEC and were performed on 11/30/11 under the conditions listed below.
Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit
for the sound power level for your model.
General Conditions: Sunny
Temperature: 47
o
F (8.3
o
C)
Wind Speed: 9 mph (14.5 kph)
Wind Direction: South
Humidity: 25%
Barometric Pressure: 30.07” Hg (101.83 kPa)
VIBRATION DATA
VIBRATION LEVEL .3g (3.13 m/s
2
)
Vibration levels at the operator’s handles were measured in the vertical, lateral and longitudinal directions using calibrated vibration test
equipment. Tests were performed on 11/30/11 under the conditions listed below.
General Conditions: Sunny
Temperature: 47
o
F (8.3
o
C)
Wind Speed: 9 mph (14.5 kph)
Wind Direction: South
Humidity: 25%
Barometric Pressure: 30.07” Hg (101.83 kPa)
112 dB
