Billy Goat FM3301EB - Parts List

Part No 520187 Form No F010408A
19
FM Owner’s Manual
PARTS LIST
ITEM
FM3301EB
NO.
Part NO.
1 BUSHING BRONZE 520184 4
2 LABEL DANGER FLY 810736 1
5 LABEL WARNING 400424 2
7 LABEL HGT. GUIDELINE 520043 1
16 SPRING EXHAUST CHUTE 510205 1
17 LABEL WARNING MOWER 510206 1
18 BLADE 11.88” 520001 3
20 LYNCH PIN 3/16” X 1 9/16 520004 2
21 WHEEL AND TIRE 8” ASSY. 520005 2
23 BELT SPINDLE DRIVE 520007 1
24 SPINDLE ASSY FM 520008 3
33 WASHER 1/2 INNER TOOTH 520025 3
35 SCREW CAP 1/2-20X1.25 520028 3
38 BUSHING CASTER SPACERS 520034 12
41 SPACER FRONT CASTER 520041 2
42 EXHAUST CHUTE DEFLECT. 520042 1
46 PULLEY DECK FRONT DRIVE 520047 1
53 CASTER ARM FM WA 520067-S 2
56 DECK WA W/ LABELS 520071-S 1
62 BRACKET CASTER FM WA 520077 2
65 PLUG 3/8” BUTTON HEAD 520081 2
71 WIRE BELT FINGER 520088 1
81 GUARD BELT W/ LABELS FM 520100-S 1
87 KNOB 3 PRONG 1/4” 520109 4
103 WASHER 1/2” X 2 610308-P 3
119 LABEL DANGER 900327 1
126 BOLT CARRIAGE 3/8-16X1” ZP 8024058 5
127 BOLT CARRIAGE 3/8-X 1 1/4 8024059 16
130 SCREW CAP 1/4 - 20 X 7" 8041023 1
139 SCREW CAP 1/2-13 X 4 1/2 8041107 2
144 NUT 3/8-16 LOCK NYLON 8160003 21
145 NUT 1/2-13 LOCK NYLON 8160005 2
147 NUT 1/4-20 LOCK NYLON 8160001 1
151 WASHER 5/16” FC 8171003 20
155 WASHER 3/4 FC 8172015 4
163 HOUSING SPINDLE 520008-01 3
164 SHAFT SPINDLE 1215 C. D. S. 520008-02 3
165 BEARING BALL 6305-25 520008-03 6
166 WASHER 520008-04 3
167 SHIELD 520008-05 3
168 RETAINING RING 520008-06 6
169 RETAINING RING 520008-07 3
170 WOODRUFF KEY # 605 520008-08 3
171 PULLEY 4.75” DIA. 3/4” BORE 520008-09 3
172 MACHINERY BUSHING 3/4” 520008-10 3
173 NUT 3/4-16 NYLON HEX 520008-11 3
174 FRONT CASTER ASSY. 520140 1
175 BEARING CASTER WHEEL 520124 4
178 LABEL BGI BIG CIRCLE 430303 1
179 LABEL 33" CUT FM 520115 1
180 LABEL MADE IN USA 520116 1
189 FITTING GREASE 610363 2
DESCRIPTION QTY
