Part No 520187 Form No F010408A
3
FM Owner’s Manual
SERIAL PLATE DATA
Record the model number, serial number, date of
purchase, and where purchased.
Purchase Date:
Purchased From:
Specifications
FM3301EB
Engine: HP 13 (9.7 kW)
Engine: Model 21A9070147
Engine: Type B & S INTEK OHV Elec.
Engine: Fuel Capacity 3.0 qt. (2.8 L)
Engine: Oil Capacity 1.5 qt. (1.4 L)
Total Unit Weight: 267# (121 Kg)
Max. operating slope 15
o
Overall length 57” (1.44m)
Overall width 43” (1.09m)
Overall height 47” (1.19m)
In accordance with 2000/14/EEC 108dBa
Sound at operators position 88dBa
Vibration at operator position 2.65g
