Billy Goat FM3301EB - Page 23

Part No 520187 Form No F010408A
23
FM Owner’s Manual
PARTS LIST
ITEM
FM3301EB
NO.
Part NO.
19 BELT TRANS DRIVE FM 520201 1
22 BELT BLADE DRIVE FM 520006 1
25 SPRING TORSION WIRE 520009 1
26 TRANSAXLE 5SPD FM 520010 1
27 BRACKET T-AXLE SUPPORT 520016 1
36 BOLT SHOULDER 1/2” X 2” 520031 1
39 SPRING BRAKE 520037 1
48 PULLEY 6.875 OD 4LV GROOVE 0.625 BORE 520198 1
54 SHIFT LINKGAGE WA FM 520068 1
57 BRKT IDLER GRND DRIVE 520203 1
61 BASE ENGINE W/INSERTS 520177 1
63 BRACKET BELT GUIDE DRV 520196 1
70 GROMMET RUBBER 1” 520087 2
73 GROMMET RUBBER 1.25” 520092 1
101 ROLL PIN 1/4” X 1.0 IN LONG 520156 1
105 PULLEY IDLER TENSION 800260 1
108 TUBE PIVOT IDLER VQ 830526 1
110 RING SNAP 0.75 850230 2
112 SCREW CAP 1/4-28X1/2” GR 5 850408 1
124 BOLT CARR. 1/4-20X1.25” 8024023 1
125 BOLT CARR. 5/16-18X1 1/2” 8024042 2
127 SCREWCAP 3/8-16 X 1 3/4 8041053 1
129 SCREWCAP 1/4"-20 X 2.75" 8041013 1
132 SCREWCAP 5/16-18 X 1.25" 8041029 1
136 SCREW CAP 5/16 - 18 x 2.75 8041035 4
141 SCREW SELF TAP 5/16 8123128 1
142 NUT LOCK 1/4-20 NYLON 8160001 2
143 NUT LOCK 5/16-18 NYLON 8160002 4
144 NUT LOCK 3/8-16 NYLON 8160003 1
147 NUTLOCK 3/8”-16 LW TH ZP 8161042 1
150 WASHER 1/4” FC 8171002 5
151 WASHER 5/16” FC 8171003 3
152 WASHER 1/4 SAE 8172007 1
155 WASHER 3/4 FC 8172015 6
156 WASHER LOCK 5/16 SPLIT 8177011 5
157 WASHER LOCK 1/4” EXT. 8181007 1
158 KEY 3/16 x 2 1/8 9201087 2
160 WASHER 3/4 THIN 850238 2
162 WHEEL AND TIRE 13” 830177 2
176 NUT JAM 1/4-20 8143001 2
182 NUT JAM 5/16 8142002 2
186 RING SNAP 5/8 T.A. 850233 1
188 WASHER .765 ID X 1.25 OD X .06 850238 1
DESCRIPTION QTY
