Billy Goat FM3301EB - Page 25

Part No 520187 Form No F010408A
25
FM Owner’s Manual
PARTS LIST
ITEM
FM3301EB
NO.
Part NO.
3 PALNUTS 3/8” 360218 2
8 KNOB 1/2” THREAD 430128 1
10 LABEL CLUTCH DRIVE 500176 1
11 LABEL BLADE DRIVE 500177 1
12 GRIP HANDLE 1” x 7” 500267 1
14 SWITCH ELECTRIC W/ NUT 500307 1
28 SPRING COMPRESSOR 1/2” 520017 1
30 CONTROL THROTTLE POS 520019 1
31 ROD SHIFT LINKGAGE 520179 1
32 BAR HANDLE BRACE FM 520024 2
34 HANDLE RH FM 520026-S 1
47 LABEL CONSOLE 520048 1
52 LABEL READ MANUAL 890301 1
60 SHIFT LOCK HANDLE FM WA 520075 1
66 CABLE CLUTCH BLADE FM 520083 1
67 CABLE CLUTCH DRIVE FM 520204 1
68 CABLE CLUTCH BRAKE FM 520085 1
69 BUSHING NYLON 500130 1
82 HANDLE LH FM 520091-S 1
74 LEVER CONTROL BRAKE FM 520093-S 1
75 LEVER CONTROL DRIVE FM 520094 1
76 LEVER CONTROL BLADE FM 520095 1
77 PLATE REV LOCK OUT 520096 2
78 BRACKET SHIFT PIVOT FM 520097 1
79 GRIP LEVER ORANGE 520098 1
80 CONSOLE FM W/ LABELS 520146 1
82 CUP HOLDER 520102 1
95 LABEL PUSH TO RELEASE 520117 1
97 CLEVIS PINS 3/8 - 1.625 520119 1
98 CLEVIS PINS 3/8 - 2.125 520120 1
99 GRIP LEVER 0.125-1.00-3.75 520121 1
100 GRIP LEVER 0.125-0.75X3.75 520121 1
113 PLUG TUBE INSERT 1” 520122 2
114 LABEL EAR-EYE-BREATHE 890132 1
116 SCREW 1/4” - 20 X 5/8 890254 2
117 PIN CLEVIS 5/16-24 890359 1
121 TY-WRAP 830513 4
122 PAL NUTS 5/16” 900407 1
123 BOLT CARRIAGE 5/16-18 X 3/4 360203 6
134 SCREW CAP 5/16-18 X 2 8041032 1
135 SCREWCAP 5/16-18 x 2 1/4 8041033 4
143 NUT LOCK 5/16-18 NYLON 8160002 9
144 NUT LOCK 3/8-16 NYLON 8160003 2
150 WASHER 1/4” FC 8171002 12
153 WASHER 5/16 SAE 8172008 2
154 WASHER 1/2” SAE ZP 8172011 2
177 LABEL BGI OVAL FM 520110 1
185 RETAINING RING EXTERNAL 520176 1
191 WASHER 5/16” FC 8171003 4
DESCRIPTION QTY
