OVERSEEDER/POWER RAKE Owner’s Manual
Part No 350412 350412_E_HI
PARTS LIST PR/OS
PR550 QTY PR550H QTY OS552 QTY OS552H QTY
no. LIST Part No. Part No. Part No. Part No.
1 PULLEY PR550/0S550 350440 1 350440 1 350440 1 350440 1
1A Spacer 5/8 OD X 3/8 ID X 1.0 LG 350401 3 350401 3 350401 3 350401 3
2 Pulley 6.5" OD X ¾" 350102 1 350102 1 350102 1 350102 1
3 WHEEL 8.0" X 5/8" BEARING 350103 2 350103 2 350103 2 350103 2
4 WHEEL 10.0" X 5/8" BEARING 350104 2 350104 2 350104 2 350104 2
5 HT ADJ ASSY PR 350107-S 1 350107-S 1 350107-S 1 350107-S 1
6 Reel Flail / Slicing / Spring Assy 350112 1 350112 1 350336 1 350336 1
7 Pulley Idler 2.75" 350114 1 350114 1 350114 1 350114 1
8 Arm Idler WA 350115 1 350115 1 350115 1 350115 1
9 Belt 5L X 36 350116 1 350116 1 350116 1 350116 1
10 Screwcap 5/16" x 24 x 1 1/2 Gr5 HCS 8042030 1 8042030 1 8042030 1 8042030 1
11 Bracket Mount Clutch Cable 350119 1 350119 1 350119 1 350119 1
12 Chassis WA W/ Label 350194 1 350194 1 350194 1 350194 1
13 Frame Front WA 350121 1 350121 1 350121 1 350121 1
14 Bushing 0.375 OD X 0.256 ID X 0.88 350309 1 350309 1 350309 1 350309 1
15 Spring Height Adjust PR500 350125 1 350125 1 350125 1 350125 1
16 Link Height Adjust PR500 350126 1 350126 1 350126 1 350126 1
17 Yoke ½ - 20 350127 1 350127 1 350127 1 350127 1
18 Pin Yoke ½" 350128 1 350128 1 350128 1 350128 1
19 Bracket Mount Hgt. Adj. WA 350182 1 350182 1 350182 1 350182 1
20 Spacer Spanner Wheel PR500 350130 4 350130 4 350130 4 350130 4
21 GUARD, BELT W/LABELS OS/PR 350384-S 1 350384-S 1 350384-S 1 350384-S 1
22 GUARD SHAFT WA W/LABELS 350196-S 1 350196-S 1 350196-S 1 350196-S 1
23 Bearing ¾" Cast Pillow Block 350133 2 350133 2 350133 2 350133 2
24 Handle Lower LH WA 350134 1 350134 1 350134 1 350134 1
25 Handle Lower RH WA 350135 1 350135 1 350135 1 350135 1
26 Handle Upper PR500 350375 1 350375 1 350375 1 350375 1
27 Bail Clutch WA 350374 1 350374 1 350374 1 350374 1
28 Loop Folding Handle 350138 2 350138 2 350138 2 350138 2
29 Deflector Rubber 350167 1 350167 1 350167 1 350167 1
30 Shield Bearing 350168 2 350168 2 350168 2 350168 2
31 Bar Clamp Deflector 350171 1 350171 1 350171 1 350171 1
32 Bracket Height Adjust Lock WA 350173 1 350173 1 350173 1 350173 1
33 Guard Pulley Back 350400 1 350400 1 350400 1 350400 1
34 Lever Height Control 350175 1 350175 1 350175 1 350175 1
35 Label Instr. Hgt. Adj. 350176 1 350176 1 350176 1 350176 1
36 Bolt Shoulder ¼" x 1 ¾" 350178 1 350178 1 350178 1 350178 1
37 Bolt Shoulder 5/16" x 1 ¾" 350179 1 350179 1 350179 1 350179 1
38 Cable Clutch PR 350408-S 1 350408-S 1 350408-S 1 350408-S 1
40 BOLT SHOULDER 1/2" X 1" 500114 1 500114 1 500114 1 500114 1
41 ENGINE HONDA 5.5 H.P. GX160 - - 600115 1 - - 600115 1
ENGINE 5.5 HP B&S VANGUARD 350379 1 - - 350379 1 - -
42 KEY 3/16" X 1" 9201078 1 9201078 1 9201078 1 9201078 1
43 GRIP 1" x 13" 400570 2 400570 2 400570 2 400570 2
44 GRIP LEVER 1/8 x 1 x 5" 500181 1 500181 1 500181 1 500181 1
45 LABEL INSTRUCTION SEEDER BOX - - - - 350288 1 350288 1
46 LABEL PR BADGING 350422 1 350422 1 350422 1 350422 1
47 FINGER BELT WIRE 350301 1 350301 1 350301 1 350301 1
48 LABEL DANGER THROWN OBJECT 810736 1 810736 1 810736 1 810736 1
49 LABEL CLUTCH VQ 830503 1 830503 1 830503 1 830503 1
50 LABEL WARNING FUEL EN/SP 100261 1 - - 100261 1 - -
51 LABEL WARNING 400424 2 400424 2 400424 2 400424 2
52 LABEL DANGER GUARD 900327 1 900327 1 900327 1 900327 1
53 PLUG CAP 1" RD 890132 2 890132 2 890132 2 890132 2
54 BOLT CARRAIGE 3/8-16 x 1 3/4 8024061 4 8024061 4 8024061 4 8024061 4
55 BOLT CARRAIGE 5/16-18 x 1 3/4 8024043 2 8024043 2 8024043 2 8024043 2
56 BOLT CARRIAGE 5/16 -18 x 3/4 8024039 4 8024039 4 8024039 5 8024039 5
57 WASHER LOCK 3/8" S/T MED 8177012 1 8177012 1 - - - -
WASHER LOCK 5/16" TW TOOTH - - - - 430298 1 430298 1
58 NUT LOCK #10-24 8164005 1 8164005 1 8164005 1 8164005 1
59 NUT LOCK 1/4-20 8160001 2 8160001 2 8160001 5 8160001 5
60 NUT LOCK 3/8-16 8160003 12 8160003 12 8160003 12 8160003 12
62 NUT LOCK 5/16-18 8160002 15 8160002 15 8160002 16 8160002 16
63 SCREWCAP 1/4-20 x 1 1/2 8041008 1 8041008 1 8041008 1 8041008 1
64 SCREWCAP 3/8 - 16 x 1 3/4 8041053 1 8041053 1 8041053 1 8041053 1
