Binks MODELS 84-598 & 84-599 REMOTE FLUID PRESSURE REGULATORS
AUTOMATIC CONTROL METHOD – CLOSED LOOP
Closed-Loop
Controller
Metered
Fluid
Flow
Atomizing Air
Pressure Regulator
Atomizing Air
Pressure Regulator
Air Supply
(0-100 psi)
Control Air
Pressure
Fluid Regulator
84-598 or 84-599
Unregulated
Fluid
Fluid
Recirculating
Line
(If required)
FLOW METER
Electric Solenoid
ATOMIZING AIR
TRIGGER ON/OFF AIR
REGULATED FLUID
I/P or E/P
Transducer
