ROD SEAT
1
ROD SEAT SEAL 1
UPPER BALL, 6mm 1
22
0115-010149 INLET 3/4" NPS(m) FX4 ONLY 1
0115-010070 INLET 1/2" NPS(m) FXL4 ONLY 1
24
1
SEAL
0115-010056 LOWER PUMP TUBE 1
0115-010068 LOWER SEAT SEAL 2
0115-010057 LOWER BALL CAGE 1
0114-014237 LOWER BALL, 15mm 1
0115-010069 LOWER SEAT 1
0115-010099 ROD CLIP (not shown) 2
0115-010256 FX4 CHECK VALVE ASSEMBLY - FXL4 ONLY
1
0115-010063 PUMP ROD (HARD CHROME) 1
0114-014745 UPPER BALL, 6mm 1
0115-010065 ROD SEAT SEAL 1
0115-010066 ROD SEAT 1
0115-010067 ROD SEAT NUT 1
0115-010169 LOWER SEAL CARTRIDGE ASSEMBLY 1
0115-010061 SOLVENT CUP SEAL 1
0115-010062 PACKING ADAPTER 1
0115-010058 WAVE SPRING 1
0115-010204 ADAPTER PLATE MACHINING 1
0115-010166 UPPER SEAL CARTRIDGE ASSEMBLY 1
0115-010055 UPPER PUMP TUBE 1
FX4 & FXL4 Fluid Section (U-cup seals)
1
Models: FX4UC & FXL4UC
ITEM PART NUMBER DESCRIPTION QTY.
0115-010646 PUMP TIE ROD 3
0115-010059 SOLVENT CUP 1
0115-010060 SIGHT GAUGE 1
CHECK VALVE SPRING
1
•
Parts are included in 0115-010219 Seal Kit (U-CUPS).
+
Parts are included in 0115-010220 Repair Kit (U-CUPS).
FLUID OUTLET FITTING
CHECK VALVE HOUSING
1
