77-2946
page 6
4. Open the ball valve for the compressed
air supply and use the pressure
regulator (0115-010183) to set the
compressed air supply to 1 bar (14.5
psi). The pump will now draw in the
spray material. The spray material flows
back into the tank through the high
pressure filter, the high pressure ball
valve and the return pipe.
5. Remove the spray tip from the gun and
point the gun into a suitable container.
Unlock the safety lever on the gun.
Operate the gun trigger and close the
high pressure ball valve (0114-019091).
The spray material will now flow
through the high pressure filter, the
fluid hose and the gun, back into the
container.
6. Release the gun trigger and set the
working pressure at the regulator.
WORK STOPPAGES
For work stoppages of between 10 and 30
minutes, please proceed as follows:
1. Lock the safety lever on the gun.
2. Shut off the compressed air supply by
closing the ball valve.
3. Briefly open the high pressure ball valve
(0114-019091) until the pressure has
reduced. Then close the high pressure
ball valve again.
4. Clean the outside of the spray nozzle
from spray material residue.
SHUT-DOWN
1. Close the ball valve for the compressed
air supply.
2. Carefully open the high pressure ball
valve (0114-019091) to reduce the
pressure in the pump and in the high
pressure filter.
3. Remove the spray tip from the gun.
4. Point the gun into a container and
operate the trigger to reduce any
pressure which may still exist in the
fluid hose and in the gun.
5. Lock the safety lever on the gun.
6. Remove the pump/lid from the pail.
CLEANING YOUR BINKS PUMP
1. Clean the pump from the outside. Clean
the pail and fill with cleaning solvent.
Replace the pump/lid.
2. Clean the fluid tip/tip system as
described in the service bulletin of the
spray gun. We recommend to soak the
fluid tip in solvent.
3. Unlock the safety lever of the gun
without fluid tip. Operate the gun. Close
the high pressure ball valve (0114-
01909). Set the air inlet pressure to 1
bar (14.5 psi) and slowly open the ball
valve. Let the solvent run through the
system so that the spraying material
can rinse out.
4. Let the solvent run through the system
for a couple of minutes until the solvent
runs clear through the gun. Close the
ball valve and lock the safety lever of
the gun.
5. Clean the gun from the outside and
check the filter on the handle (if
mounted).
6. Clean the filter element of the high
pressure filter.
7. Clean the filter of the suction system.
8. We recommend keeping the pump
filled with liquid.
MAINTENANCE
Follow the manual 77-2907 supplied
with the pump for pump
maintenance.
See pages 7 to 12 for exploded views,
spares part numbers, and strip down
procedure.
CAUTION
Once work is completed, the BINKS
pump must be thoroughly cleaned.
Under no circumstances must the paint
residue be allowed to dry out in the
pump. To clean the pump, use a
solvent appropriate to the spray
material.
CAUTION
Do not allow spray material or solvent
to soak into the ground.
NOTE
Before carrying out any coating work,
we recommend a test spray (e.g. onto
paper or wood). Only if the test gives
you the desired result should you start
to coat the actual object.
CAUTION
When work I stopped, the safety lever
of the gun must be locked.
WARNING
Wear Eye protection
WARNING
Wear Eye protection
NOTE
If the pump is not to be used for
longer periods of time, we recommend
flushing the system with a light,
silicone-free oil.
CAUTION
I working with 2-K spray material, you
must note the given pot life and follow
it precisely. Within this time, the unit
must be carefully cleaned and rinsed
with the recommended solvent. There
must be no residue left in the pump,
the high pressure filter of the gun.
