Binks MX432 - Wall Mounted Assemblies

77-2946
page 8
ITEM No PART NUMBER DESCRIPTION QTY
1 0114-016061 GASKET 1
2
0110-009132 FILTER SCREEN 100 MESH (STD) 1
0115-009131 FILTER SCREEN 50 MESH 1
0115-009133 FILTER SCREEN 150 MESH 1
0115-009060 FILTER SCREEN 200 MESH 1
3 0114-013730 NIPPLE 1/4” NPSM 1
4 0114-019090 NIPPLE 1
5 0114-019091 HIGH PRESSURE BALL VALVE 1
6 0114-0200027 ELBOW 1
7 0114-019985 HOSE NOZZLE 1
8 0115-010600 PLUG 1
9 20-2828 ELBOW SS HIGH PRESSURE 1
10 0114-016243 GROUND WIRE KIT (NOT SHOWN) 1
SPECIFICATION
Max working pressure 272 bar (3950 psi)
Fluid inlet connection 1/4” NPSM
Fluid outlet connection 1/4” NPSM
Wetted parts material of
construction
Stainless steel, PTFE
0115-010200 FILTER ASSEMBLY
