EN
77-2841-R6 (6/2018) 5 / 12 www.carlisleft.com
MODEL 80-600 SG-2 PLUS
TM
PRESSURE CUP (Standard)
1 80-375 2 QT CANISTER ASM .................... 1
2 80-376+ 2 QT CANISTER SUB-ASM ............ 1
3 20-4870+❍ SPIROL PIN .................................... 4
4 80-381+❍ CANISTER KNOB SWIVEL ............. 4
5 80-380+❍ CANISTER KNOB ........................... 4
6 80-382+❍ RETAINING RING ........................... 4
7 80-355● DISPOSABLE LINER ....................... 1
8 80-392* LID GASKET ................................... 1
9 80-602 COVER MACHINING ..................... 1
10 80-606 CHECK VALVE ASM ..................... 1
11 80-610 DIFFUSER ....................................... 1
12 80-389 FLUID TUBE NUT .......................... 2
13 80-388* FLUID TUBE SEAL ......................... 2
14 80-613 FLUID TUBE ASM .......................... 1
15 83-2484 DM NIPPLE, 1/4 NPT X 3/8 NPS .... 1
16 20-6582 SCREW ........................................... 2
17 80-373* HANDLE GASKET .......................... 1
18 80-604 MANIFOLD .................................... 1
19 80-12 RELIEF VALVE ................................ 1
20 20-353-1 JAM NUT, 5/16-18 ........................ 1
21 80-605 HANDLE ........................................ 1
22 85-449 REGULATOR ASM (15# gauge) .... 1
23 85-436 REGULATOR BODY ....................... 1
24 72-104 TAIL PIECE ..................................... 1
25 72-93 SWIVEL NUT, 1/4 NPS ................... 1
PARTS LIST
(When ordering, please specify Part No.)
ITEM PART
NO. NO. DESCRIPTION QTY.
26 54-308 AIR CONNECTION ......................... 1
27 TIA-4326* SAFETY VALVE .............................. 1
28 59-299 GAUGE, 15 PSI ............................. 1
29 71-28 DM NIPPLE, 1/8 NPT X 1/4 NPS ... 1
30 85-437* REGULATOR KIT, 15 PSI ................ 2
31 ——
▫ VALVE SPRING .............................. 1
32 ——
▫ VALVE, PTFE .................................. 1
33 ——
▫ O-RING .......................................... 1
34 ——
▫ VALVE SEAT .................................. 1
35 ——
▫ DIAPHRAGM ................................. 1
36 ——
▫ VALVE SPRING .............................. 1
37 ——
REGULATING SPRING ................... 1
38 ——
NUT ............................................... 1
39 ——
STEM ............................................. 1
40 ——
BONNET ........................................ 1
41 80-616 TOP OUTLET PLUG ....................... 1
*
Part of 80-617 Pressure Cup Repair Kit
+
Part of 80-375 2Qt Canister Assy.
❍ Part of 80-390 Knob Replacement Kit
● Available only as a quantity pack (See Accessories, 80-356, below)
Used in 85-449 Regulator Assembly
Part of 85-437 Regulator Kit (NOT available separately)
▫ Part of KK-4887-2 Regulator Repair Kit
ITEM PART
NO. NO. DESCRIPTION QTY.
PART
NO. DESCRIPTION QTY.
80-356 CANISTER LINER QTY. PACK OF 80-355 ...... 12/pk.
HAV-500 AIR ADJUSTING VALVE ............................ 1
HAV-501 AIR ADJUSTING VALVE W/GAUGE ......... 1
ACCESSORIES
(Not furnished, please order separately.)
PART
NO. DESCRIPTION QTY.
85-437 REGULATOR KIT, (10# SPRING) .................... 1
80-373 HANDLE GASKET ..................................... 1
80-388 FLUID TUBE SEAL ..................................... 2
80-392 LID GASKET .............................................. 1
TIA-4326 SAFETY VALVE ......................................... 1
80-617 PRESSURE CUP REPAIR KIT
(LOW PRESSURE – 10# SPRING)
PART
NO. DESCRIPTION QTY.
59-369 GAUGE, (
60 PSI)
......................................... 1
85-438 REGULATOR KIT, (50# SPRING) .................... 1
85-243 SAFETY VALVE ......................................... 1
80-619 HIGH PRESSURE CONVERSION KIT
NOTE
To convert to High Pressure Kit (0-50 psig), see page 8.
98-1263 OUTFIT
MACH 1SL Gun with Standard cup
consisting of:
80-600 STEADI-GRIP 2 QT. PRESSURE POT (Std.).
HAV-501 AIR FLOW CONTROLLER,
Mounted on gun inlet.
MACH 1SL HANDGUN with 92 FLUID NOZZLE
by 94P AIRCAP ASSEMBLY.
71-1201 AIR HOSE, 1/4" x 5' Long.
71-3380 FLUID HOSE, 3/8" x 5' Long.
Binks STEADI- GRIP 2 OUTFIT
HVLP GUN OUTFITS
