Binks SG-2 PLUS 80-600 - Model 80-601 Parts List; Agitator Repair and Conversion Kits

EN
77-2841-R6 (6/2018) 7 / 12 www.carlisleft.com
MODEL 80-601 SG-2 PLUS
TM
PRESSURE CUP WITH OSCILLATING AGITATOR
1 80-375 2 QT CANISTER ASM .......................... 1
2 80-376+ 2 QT CANISTER SUB-ASM .................. 1
3 20-4870+❍✝ SPIROL PIN .......................................... 4
4 80-381+❍✝ CANISTER KNOB SWIVEL ................... 4
5 80-380+❍✝ CANISTER KNOB ................................. 4
6 80-382+❍ RETAINING RING ................................ 4
7 80-355• DISPOSABLE LINER (See 80-356 below) 1
8 80-392* LID GASKET ........................................ 1
9 80-603 COVER MACHINING ........................... 1
10 80-606 CHECK VALVE ASM ........................... 1
11 80-610 DIFFUSER............................................. 1
12 80-389 FLUID TUBE NUT ................................ 2
13 80-388* FLUID TUBE SEAL ............................... 2
14 80-613 FLUID TUBE ASM ................................ 1
15 83-2484 DM NIPPLE, 1/4 NPT X 3/8 NPS .......... 1
16 20-6582✝ SCREW................................................. 2
17 80-373* HANDLE GASKET ................................ 1
18 80-604 MANIFOLD .......................................... 1
19 80-12 RELIEF VALVE ...................................... 1
20 20-353-1 JAM NUT, 5/16-18 .............................. 1
21 80-605 HANDLE .............................................. 1
22 85-449 REGULATOR ASM (15# gauge) .......... 1
23 85-436 REGULATOR BODY ............................. 1
24 72-104 TAIL PIECE ........................................... 1
25 72-93 SWIVEL NUT, 1/4 NPS ......................... 1
26 54-308 AIR CONNECTION ............................... 1
27 TIA-4326 SAFETY VALVE* .................................. 1
28 59-299 GAUGE, 15 PSI ................................... 1
29 71-28 DM NIPPLE, 1/8 NPT X 1/4 NPS ......... 1
30 85-437*◊ REGULATOR KIT, 15 PSI ...................... 2
31 ——

▫ VALVE SPRING .................................... 1
32 ——

▫ VALVE, PTFE ........................................ 1
33 ——

▫ O-RING ................................................ 1
34 ——

▫ VALVE SEAT ........................................ 1
35 ——

▫ DIAPHRAGM ....................................... 1
36 ——

▫ VALVE SPRING .................................... 1
37 ——

REGULATING SPRING ......................... 1
38 ——

NUT ..................................................... 1
39 ——

STEM ................................................... 1
40 ——

BONNET .............................................. 1
41 80-616 TOP OUTLET PLUG ............................. 1
42 82-740 AIR CONTROL VALVE ASSEMBLY ...... 1
43 82-745  VALVE BODY ASSEMBLY .................... 1
PARTS LIST
(When ordering, please specify Part No.)
ITEM PART
NO. NO. DESCRIPTION QTY.
44 81-307  BARBED CONNECTOR ........................ 1
45 20-3236 ✖ O-RING ................................................ 1
46 82-747  STEM ................................................... 1
47 73-44  NUT ..................................................... 1
48 73-46  CAP...................................................... 1
49 20-2606  SCREW 8-32 x 3/8" Oval Hd ............... 1
50 54-3929 TUBE 6-1/2 " Nylon ............................ 1
51 81-307 BARBED CONNECTOR ........................ 1
52 82-728 INLET FITTING ..................................... 1
53 82-729 EXHAUST FITTING .............................. 1
54 82-730 ✖ GASKET ............................................... 2
55 80-611 SG2 PLUS OSCILLATING AGITATOR ASSY .. 1
56 82-727 ✖ CYLINDER GASKET ............................. 1
57 82-720 ✖ CONICAL SPRING ................................ 1
58 20-5845 ✖ O-RING ................................................ 1
59 82-714 ✖ PISTON ASSEMBLY ............................. 1
60 82-779 PISTON ROD ....................................... 1
61 82-721 ✖✝ COMPRESSION SPRING ...................... 1
62 82-711 CYLINDER ASSEMBLY ......................... 1
63 20-3753 ✖ O-RING ................................................ 1
64 82-776 ✖ CAN SEAL ............................................ 1
65 82-777 INNER RING ........................................ 1
66 82-753 INNER MAGNET .................................. 1
67 20-6022✝ SCREW 1/4-28 x 3/4" Hex Hd ............. 1
68 82-775 ✖ CAN ..................................................... 1
69 82-778 CAN RETAINER ................................... 1
70 20-6023✝ SCREW 12-24 x 1/2" Flat Hd .............. 1
71 82-770 OUTER MAGNET ASSEMBLY .............. 1
72 80-406 OSCILLATING AGITATOR POST .......... 1
73 80-615 OSCILLATING AGITATOR PLATE ......... 1
74 20-2530✝ #10 EXTERNAL STAR WASHER .......... 1
75 20-5832✝ SCREW 10-32 x 3/8" Pan Hd .............. 1
76 20-6790✖✝ GROMMET .......................................... 1
*
Part of 80-617 Pressure Cup Repair Kit
+ Part of 80-375 2Qt Canister Assy.
❍ Part of 80-390 Knob Replacement Kit
 Part of 82-740 Air Control Valve Assembly
 Used in 85-449 Regulator Assembly

Part of 85-437 Regulator Kit
▫ Part of KK-4887-2 Regulator Repair Kit
✖
Part of 80-612 Oscillating Agitator Repair Kit
ITEM PART
NO. NO. DESCRIPTION QTY.
PART
NO. DESCRIPTION QTY.
20-3236-5• O-RING ........................................................................ 1
82-730 GASKET ....................................................................... 2
82-727 CYLINDER GASKET ..................................................... 1
82-720 CONICAL SPRING ........................................................ 1
20-5845 O-RING ........................................................................ 1
82-721 ✝ SPRING ........................................................................ 1
20-3753 O-RING ........................................................................ 1
82-776 CAN SEAL .................................................................... 1
82-775 CAN ............................................................................. 1
20-6790 ✝ GROMMET .................................................................. 1
82-714 PISTON ASSEMBLY ..................................................... 1
80-612 OSCILLATING AGITATOR REPAIR KIT
(Model 80-601 SG2 Plus Pressure Cup with Oscillating Agitator.)
PART
NO. DESCRIPTION QTY.
80-356 CANISTER LINER QTY. PACK OF 80-355 ................. 12/pk.
HAV-500 AIR ADJUSTING VALVE .............................................. 1
HAV-501 AIR ADJUSTING VALVE W/GAUGE ............................ 1
ACCESSORIES
(Not furnished, please order separately.)
PART
NO. DESCRIPTION QTY.
85-437 REGULATOR KIT, (10# SPRING) .................................. 1
80-373 HANDLE GASKET ........................................................ 1
80-388 FLUID TUBE SEAL ....................................................... 2
80-392 LID GASKET................................................................. 1
TIA-4326 SAFETY VALVE ............................................................ 1
80-617 PRESSURE CUP REPAIR KIT
(LOW PRESSURE – 10# SPRING)
PART
NO. DESCRIPTION QTY.
59-369 GAUGE, (60 PSI) .......................................................... 1
85-438 REGULATOR KIT, (50# SPRING) .................................. 1
85-243 SAFETY VALVE ............................................................ 1
80-619 HIGH PRESSURE CONVERSION KIT
• Available only as a quantity pack.
✝ Items NOT available separately.
