Bio Compression Systems SC-2004-OC - Key Functions

FRONT PANEL—SC-2008-OC
Key Funcons
(Note: SC-2008-OC and SC-2004-OC, SC-2004FC-OC same key funcons. No Auxiliary Air Supply Ports on the SC-2004-OC/SC-2004FC-PC)
LATCH CONNECTORS
Aach and detach the garment to the pump via the Receptor Ports (for Tubing Latch Connector
Bars), depicted by #4 in the illustraon above. A second garment may be aached to the Auxiliary
Air Supply Ports for bilateral use. (IMPORTANT: Keep the Blocker bars installed for single garment use).
TUBING
Responsible for delivering air to and from the pump and garment.
COMPRESSION GARMENT
Garment with 4 or 8 chambers, which works in conjuncon with the Sequenal Circulator to apply controlled,
sequenal pressure throughout its chambers.
1 Power On/O Switch
2 Pressure Knob
3 Receptor Ports (for Tubing Latch Connector Bars)
4 Air Supply Ports , #1 - 4
5 Air Supply Ports , #5 - 8
6 Auxiliary Air Supply Ports (for Bilateral Use, shown with Blocker Bars Installed)
7 Photo of Blocker Bars (uninstalled)
8 Tubing Latch Connector Bars (shown on the end of Tubing)
7
8
1 2
3
5
6
4
