Bio-Tek ELx800 - Figure 16: Sample Output for the System Test (Sheet 1 of 2)

108 | Chapter 4: Performance Verification and IQ/OQ/PQ Procedures
 Note: This report may vary slightly if KC4 or KCjunior are
used.
Operator ID:______________________________________________________________
Notes:____________________________________________________________________
__________________________________________________________________________
11:00 AM 06/02/03 SYSTEM SELF TEST
Lambda: 200 Gain: 3.28 Resets: 1
Channel: Ref 1
Air: 20506 35689
Dark: 9911 10002
Delta: 10595 25687
Lambda: 405 Gain: 2.53 Resets: 2
Channel: Ref 1
Air: 20072 35592
Dark: 9914 9960
Delta: 10158 25632
Lambda: 490 Gain: 1.72 Resets: 2
Channel: Ref 1
Air: 20280 35642
Dark: 9919 9949
Delta: 10361 25693
Lambda: 550 Gain: 2.51 Resets: 1
Channel: Ref 1
Air: 20248 35530
Dark: 9914 9985
Delta: 10334 25545
Lambda: 630 Gain: 3.94 Resets: 1
Channel: Ref 1
Air: 20230 35302
Dark: 9907 10018
Delta: 10323 25284
Lambda: 999 Gain: 5.33 Resets: 1
Channel: Ref 1
Air: 19977 34186
Dark: 9900 10050
Delta: 10077 24136
Channel: Ref 1
Noise Max: 9878 9980
Noise Min: 9877 9978
Delta: 1 2
Figure 16: Sample output for the System Test (sheet 1 of 2)
Bio-Tek Instruments, Inc.
