Patient monitor User’s manual
4
Horizontal resolution 16 dots/mm（at 25 mm/s paper speed）
Vertical resolution 8 dots/mm
Paper width 50 mm
Paper length 15 m
Recording speed 12.5 mm/s, 25 mm/s, 50 mm/s
Recording waveform Maximum 3 tracks
Recording way Real-time recording, periodic recording, alarm
recording
A.5.3 Battery
Type Rechargeable lithium ion battery
Model LB-08
Size 105mm×78mm×20mm
Weight <360 g
Quantity
Q3/Q5:1
Q7: 1 or 2
Rated voltage 11.1 VDC
Capability 4000 mAh
Operating time One new and fully charged battery at 25℃ ambient
temperature, connecting SpO
2
, ECG, Temp, IBPsensor and
NIBP work on AUTO mode for 15 minutes interval.
Q3/ Q5:3.5 hours
Q7:2 hours
Charge time 6h to 100%（Standby）
Turn off delay 5 min -15 min after the low battery alarm first occurs.
Indicator of battery
capability
With
A.5.4 Mainframe LED
Physiological alarm
indicating lamp
1 (Yellow/Red)
