Patient monitor User’s manual
22
Sampling flow rate 50ml/min ± 10ml/min
Measurement
parameters
CO
2
, N
2
O, O
2
, agent (ISO, ENF, SEV, HAL, DES)
Compensations
Automatic compensation for pressure, temperature
and broadening effects on CO
2
.
Calibration
No span calibration is required for the IR bench. An
automatic zero reference calibration is performed at startup
and then every 24 hours.
Warm-up time
< 20s (Concentrations reported, automatic agent
identification enabled and full accuracy)
Typical rise time
at 50 ml/min sample
flow
CO
2
≤ 200 ms (≤ 250 ms for ISA OR+/AX+)
N
2
O ≤ 350 ms
O
2
≤ 450 ms
ISO, ENF, SEV,HAL,DES ≤ 350 ms
Total system response
time
< 3s (with 2m sampling line)
Primary agent
threshold
0.15%. When an agent is identified, concentrations will be
reported even below 0.15%.
Secondary agent
threshold
0.2 % +10% of total agent concentration
Agent identification
time
<20s (typically <10s)
Measurement range and accuracy of gas:
Gas Range Accuracy
1)
CO
2
0 to15% ±（0.3 kPa + 4% of reading）
N
2
O 0 to 100% ±（2 kPa + 5% of reading）
HAL, ENF, ISO 0 to 8%
±（0.2 kPa + 10% of reading）
SEV 0 to 10%
±（0.2 kPa + 10% of reading）
DES 0 to 22%
±（0.2 kPa + 10% of reading）
O
2
0 to 100%
±（2 kPa + 2% of reading）
awRR measurement range
0 rpm to 150 rpm
awRR measurement accuracy
±1 rpm
Note 1: The accuracy specification is valid for the operating temperature and humidity conditions
specified, except for interference specified in the table “Interfering gas and vapor effects” below.
The accuracy specification is not valid if more than two agents are present in the gas mixture. If
