Mounting the Mega 350/450

For complete viewing of the large LCD, care should be taken when mounting the unit to make sure that the display is

angled towards the driver’s eyes. Before mounting the Mega 350/450, place the box in the desired location and check the

legibility of the display in both day and night conditions. As shown below, the lower the box is placed below eye level, the

more the angle amount needs to increase for viewing.

Wiring the Mega 350/450

Dri

ver

Box

Dri

ver

Box
