Biostar A770E3 User Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Phenom II/ Athlon II processors
(Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
Northbridge: AMD 770
Southbridge: AMD SB710
Super I/O
ITE 8718
Provides the most commonly used leg acy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Mon itor
ITE's "Smart Guard ian" funct ion
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800 / 1066 / 1333
Supports DDR3 1600 (OC)
Registered DIMM and ECC DIMM is not supported
IDE Integrated IDE Contro ller
Multi-word DMA, and Ultra DMA 33/66/100/133
modes
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.5 specif icat ion co mp liant
LAN Realtek RTL 8111DL
10 / 100 /1000 Mb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1 channels audio out
High Definition Audio
Slots
PCI Express Gen2 x16 slot x1
PCI Express Gen2 x1 slot x2
PCI slot x3
Supports PCI-E Gen2 x16 expans ion cards
Supports PCI-E Gen2 x1 expansion cards
Supports PCI expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Conn ector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
On Board
Connector
Front Audio Connector x1 Supports front panel audio function

Biostar A770E3 Specifications

General

Brand	Biostar
Model	A770E3
Category	Motherboard
Language	English
