Biostar G41-M7 User Manual

G41-M7 BIOS Manual
26
South Bridge Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
South Bridge Chips et Configuration
USB 2.0 Controller [Enabled]
Audio Controller [Azalia]
Onboard Lan Contro l [Enabled]
Onboard Lan Boot R OM [Disabled]
Onboard Lan Order Boot Rom [PnP/BEV(BB S)]
SMBUS Controller [Enabled]
SLP_S4# Min. Asser tion Width [1 to 2 sec onds]
USB Functions [8 USB Port s]
MAC ID Information
Options
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
USB Functions
The item determines the number of functional USB port.
Options: 8 USB Ports (Default) / 6 USB Ports / 4 USB Ports / 2 USB Ports /
Disabled
USB 2.0 Controller
This entry is to enabled/ disabled EHCI controller only. This Bios itself may/may not
have high speed USB support. If the Bios has high speed USB support built in,the
support will be automately turn on when high speed device were attached.
Options: Enabled (Default) / Disabled
Audio Controller
This item allows you to select the Audio support.
Options: Azalia (Default) / All Disabled
Onboard Lan Control
This item allows you to enable or disable the Onboard LAN.
Options: Enabled (Default) / Disabled

Biostar G41-M7 Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
CPU Socket	LGA 775
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	8 GB
Integrated Graphics	Intel GMA X4500
Expansion Slots	1 x PCIe x16, 2 x PCI
Storage Interface	4 x SATA 3Gb/s
USB Ports	8 x USB 2.0
Video Outputs	1 x VGA
LAN	10/100 Mbps
Audio	Realtek ALC662 6-Channel
