Biostar H81MHV3 2.0 User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support Intel® Core™ i7/ i5/ i3 processors and Intel® Penum® processors/ Intel® Celeron® processors
in the LGA1150 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® H81
Memory
Supports Dual Channel DDR3 1066/ 1333/ 1600
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
Supports AHCI
2x SATA II (3Gb/s)
2x SATA III (6Gb/s)
LAN
Realtek RTL8111H-CG
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC897
5.1 Channels, High Denion Audio
USB
2x USB 3.0 port (2 on rear I/Os)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe 2.0 x1
1x PCIe 2.0 x16 Slot (x16 mode)
Rear I/Os
1x PS/2 Keyboard
1x PS/2 Mouse
1x VGA Port
1x HDMI Port
2x USB 3.0 Port
2x USB 2.0 Port
1x LAN port
3x Audio Jack
Internal I/Os
2x SATA II (3Gb/s)
2x SATA III (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
Form Factor uATX Form Factor, 190 mm x 170 mm
OS Support
Windows 7/ 8/ 8.1 / 10
Biostar reserves the right to add or remove support for any OS with or without noce.

Biostar H81MHV3 2.0 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H81
CPU Socket	LGA 1150
Memory Slots	2 x DIMM
Maximum Memory	16GB
USB Ports	2 x USB 3.0, 6 x USB 2.0
Audio	Realtek ALC662 6-Channel HD Audio
Video Outputs	1 x VGA, 1 x HDMI
Power Connector	24-pin ATX, 4-pin ATX 12V
Memory Standard	DDR3 1600/1333 MHz
Storage Interface	2 x SATA 6Gb/s, 2 x SATA 3Gb/s
LAN	Realtek RTL8111G - 10/100/1000Mb/s
Expansion Slots	1 x PCIe 2.0 x16, 2 x PCIe 2.0 x1
