Hi-Fi Z87S3+/Hi-Fi H87 S3+/Hi-Fi B85 S3+
19
CIR1: Consumer IR Header
This header is for infrared remote control and communication.
Pin Assignment
1 IrDA serial input
2 Ground
3 Ground
4 Key
5 IrDA serial output
6 IR Power
