Motherboard Manual
18
2.8 Smart Switches & Indicators
On-Board Buttons
SW_PWR1:
This is an on-board Power Switch button.
SW_RST1:
This is an on-board Reset button.
BIOS POST Code/CPU Temperature Indicator
This indicator will show POST code while booting. After the booting sequence, it
will show current CPU temperature in Celsius. Please refer to Chapter 4.3 for all
the BIOS POST codes.
