Chapter 1 Motherboard Description

5B

PS/2 Mouse / Keyboard Connectors

Pin Signal Name

1Data

2 No connect

3 Ground

4 +5 V (fused)

5Clock

6 No connect

1.4.2 USB Connectors : USB1

 :       

0", .:

  0", ! H    0", 5 .  

!

Stacked USB Connectors

Pin Signal Name

1 +5 V (fused)

USBP0- USBP1-

USBP0+ USBP1

4 Ground

Note: (1) Signal names in brackets (







) are for USB port 1.

USB1

Biostar M6VCF User Manual
