Biostar M6VCF

Chapter 1 Motherboard Description
5%;
1.8 DRAM Installation
1.8.1 DIMM
 
!""#"$"#!"#%"&'()!*
Total Bank 0 Bank 1 Bank 2
Memor
y
Size
(
MB
)
DIMM1 DIMM2 DIMM3
8 M 8M x 1 pc ---- ----
16 M 16M x 1 pc ---- ----
32 M 32M x 1 pc ---- ----
64 M 64M x 1 pc ---- ----
128 M 128M x 1 pc ---- ----
256 M 256M x 1 pc ---- ----
16 M 8M x 1 pc 8M x 1 pc ----
32 M 16M x 1 pc 16M x 1 pc ----
64 M 32M x 1 pc 32M x 1 pc ----
128 M 64M x 1 pc 64M x 1 pc ----
256 M 128M x 1 pc 128M x 1 pc ----
512 M 256M x 1 pc 256M x 1 pc ----
24 M 8M x 1 pc 8M x 1 pc 8M x 1 pc
40 M 16M x 1 pc 16M x 1 pc 8M x 1 pc
72 M 32M x 1 pc 32M x 1 pc 8M x 1 pc
136 M 64M x 1 pc 64M x 1 pc 8M x 1 pc
264 M 128M x 1 pc 128M x 1 pc 8M x 1 pc
520 M 256M x 1 pc 256M x 1 pc 8M x 1 pc
32 M 8M x 1 pc 8M x 1 pc 16M x 1 pc
48 M 16M x 1 pc 16M x 1 pc 16M x 1 pc
80 M 32M x 1 pc 32M x 1 pc 16M x 1 pc
144 M 64M x 1 pc 64M x 1 pc 16M x 1 pc
272 M 128M x 1 pc 128M x 1 pc 16M x 1 pc
528 M 256M x 1 pc 256M x 1 pc 16M x 1 pc
48 M 8M x 1 pc 8M x 1 pc 32M x 1 pc
64 M 16M x 1 pc 16M x 1 pc 32M x 1 pc
96 M 32M x 1 pc 32M x 1 pc 32M x 1 pc
160 M 64M x 1 pc 64M x 1 pc 32M x 1 pc
288 M 128M x 1 pc 128M x 1 pc 32M x 1 pc
544 M 256M x 1 pc 256M x 1 pc 32M x 1 pc
80 M 8M x 1 pc 8M x 1 pc 64M x 1 pc
96 M 16M x 1 pc 16M x 1 pc 64M x 1 pc
128 M 32M x 1 pc 32M x 1 pc 64M x 1 pc
192 M 64M x 1 pc 64M x 1 pc 64M x 1 pc
320 M 128M x 1 pc 128M x 1 pc 64M x 1 pc
576 M 256M x 1 pc 256M x 1 pc 64M x 1 pc
