Biostar M6VCF

Chapter 1 Motherboard Description
5*%
1.9.1 CD Audio-In Connectors: J7/J8
Pin No. of J7 Assignment
1
Left Channel Input
2
CD_GND
3
Right Channel Input
4
CD_GND
Pin No. of J8 Assignment
1
Left Channel Input
2 CD_GND
3 CD_GND
4
Right Channel Input
1.9.2 Telephony Connector: J9
Pin No. of J9 Assignment
1
MONO_Out
2 CD_GND
3 CD_GND
4
PHONE
1.9.3 AUX Audio in Connector: J10 (Optional)
Pin No. of J10 Assignment
1
Left channel AUX_IN
2 CD_GND
3 CD_GND
4
Right channel AUX_IN
