NF520-A2 TE/NF520-A2 SE/NF520-A2
24
Onboard Serial Port 1
Select an address and corresponding interrupt for the first and second serial
ports.
The Choices: 3F8/IRQ4 (default), Disabled, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3,
Auto.
Onboard Parallel Port
This item allows you to determine access onboard parallel port controller with
which I/O Address.
The Choices: 378/IRQ7 (default), 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
This item allows you to determine how the parallel port should function. The
default value is SPP.
The Choices:
SPP (default) Usin g Parallel port as Standard Printer P ort.
EPP Usin g Parallel P ort as Enhanced P aralle l P ort.
ECP Usin g Parallel port as Extended Capabilit ies P ort.
ECP +EPP Usin g Parallel port as ECP & EPP mode.
ECP Mode Use DMA
Select a DMA Channel for the port.
The Choices: 3 (default), 1.
Init Display First
This item allows you to decide to active whether PCI Slot or on-chip VGA first.
The Choices: PCI-Express (default), PCI Slot.
OnChip USB
This option should be enabled if your system has a USB installed on the system
board. You may need to disable this feature if you add a higher performance
controller.
The Choices: V1.1+V2.0 (default), Disabled, V1.1
