TA770 A2+ SE
9
B. Memory Capacity
DIMM Socket
Location
DDR2 Module
Total Memory Size
DIMMA1 512MB/1GB/2GB/4GB
DIMMB1 512MB/1GB/2GB/4GB
DIMMA2 512MB/1GB/2GB/4GB
DIMMB2 512MB/1GB/2GB/4GB
Max is 16GB.
C. Dual Channel Memory installation
To trigger the Dual Channel function of the motherboard, the memory module
must meet the following requirements:
Install memory module of the same density in pairs, shown in the following
table.
Dual Channel Status
DIMMA1
DIMMB1 DIMMA2 DIMMB2
Enabled O O X X
Enabled X X O O
Enabled O O O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
