Manual Overclock System (M.O.S.)
MOS is designed for experienced overclock users.
It allows users to customize personal overclock settings.
BIOS SETUP UTILI TY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyri ght 19 85-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Set ting wrong values in below sections
may cause sys tem to malfunction.
=========== Automa te Over Clock System ========== =
============ Manual Ov erClock System ============
OverClock Na vigator [Normal]
Integrated M emory Test [Disabled]
Auto OverClo ck System [V6-Tech Engine]
CPU Over Vol tage [StartUp]
Memory Over Voltage [1.95V]
Chipset Over Voltage [1.15V]
HT Over Volt age [1.20V]
CPU Frequenc y [200]
> CPU FID/VI D Control
> Memory Con figuration
> DRAM Timin g Configur ation
> Hyper Tran sport Conf iguration
Exit
Options
Normal
Automate OverClock
Manual OverClock
Options
Normal
Automate OverClo ck
Manual OverClock
↓
BIOS SETUP UTILITY
Main Advan ced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C)Copyright 19 85-200x , American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause sys tem to malfunction.
=========== Automate Over Clock System ==== =======
============ Manual Ov erClock System ============
OverClock Navigator [Manual OverClock]
CPU Over Voltage [StartUp]
Memory Over Voltage [1.95V]
Chipset Over Voltage [1.15V]
HT Over Voltage [1.20V]
CPU Frequency [200]
> CPU FID/VID Control
> Memory Configuration
Integrated Memory Test [Disabled]
> DRAM Timing Configur ation
> Hyper Transport Conf iguration
Auto OverClock System [V6-Tech Engine]
Exit
Options
Normal
Automate OverClock
Manual OverClock
CPU Overvoltage
This function will increase CPU stability when overclocking. However, the
CPU temperature will increase when CPU voltage is increased.
Memory Overvoltage
This function will increase memory stability when overclocking.
Chipset Overvoltage
This function will increase Northbridge and Southbridge chipset stability
when overclocking.
HT Overvoltage
This function will increase CPU stability when overclocking the HT ratio.
