Manual Overclock System (M.O.S.)
MOS is designed for experienced overclock users.
It allows users to customize personal overclock settings.
BIOS SETUP UTILITY
Main Advanced
PCIP nP Boot
Chip se t T-Series
vxx. xx (C)Copyright 1985-200x, American Me ga trends, Inc.
Select Screen
Select Item
Change Option
General Help
Sav e an d Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING:
=========== Automate OverClock System ===========
============ Manual OverClock System ============
Please Clear CMOS if system no display
afte r ov erclocking.
OverClock Navigator [Normal]
> G.P.U Phase Control
Integrated Memory Test [Disabled]
Aut o Ov erClock System [V6-Tech Engine ]
CPU/HT Reference Clock (MHz) [200]
CPU Configuration [Auto]
> CPU Tuning
> Clock Control
> Voltage Configuation
> D RA M Timing Configurat io n
> M em ory Configuration
Exit
Options
Normal
Automate OverClock
Man ua l OverClock
Options
Norm al
Auto ma te OverClock
Manual OverClock
↓
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx. xx (C)Copyright 1985-200x, Americ an Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Sav e an d Exit
Exit
+-
F1
F10
ESC
T-Series Settings
=========== Automate OverClock System ===========
============ Manual OverClock System ============
WARNING: Please Clear CMOS if system no display
afte r ov erclocking.
OverClock Navigator [Manual OverClock]
Aut o Ov erClock System [ V6 -Tech Engine]
CPU/HT Reference Clock (MHz) [200]
CPU Configuration [Auto]
> CPU Tuning
> Clock Control
> Voltage Configuation
> D RA M Timing Configur ation
> M em ory Configuration
> G.P.U Phase Control
Integrated Memory Test [Disabled]
Exit
Options
Normal
Automate OverClock
Man ua l OverClock
CPU/HT Reference Clock (MHz)
CPU Frequency is directly in proportion to system performance. To
maintain the system stability, CPU voltage needs to be increased also
when raising CPU frequency.
CPU Configuration
This item provides several fixed modes of CPU configuration.
CPU Tuning
Enter this function for more advanced CPU settings.
