1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+
AMD Athlon 64 / Athlon 64 FX
/
Athlon 64 x2
/ Sempron / Phenom / Phenom II pro cessors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 790GX (TA790GXBE)
AMD 785G (TA785 A2+)
AMD SB750 (TA790GXBE)
AMD SB710 (TA785 A2+)
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives ,
H/W Monitor
Fan Speed Contro ller
ITE's "S mart Guardian" function
Main
Memory
DDR2 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory modu le
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ / AM3 CPU)
Registered DIMM and ECC DIMM is not supported
Graphics
AMD 790GX (Radeon HD 3300)
AMD 785G (Radeon HD 4200)
Max Shared V ideo Memory is 512 MB
DX10/UVD/HDCP support
IDE
AMD SB750 (TA790GXBE)
AMD SB710 (TA785 A2+)
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II
AMD SB750 (TA790GXBE)
AMD SB710 (TA785 A2+)
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specif icat ion co mp liant.
RAID 0,1,5,1+0 support
(RAID 5 for TA790GXBE only)
LAN
Realtek RTL 8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
ALC662
5.1channels audio out
Supports HD Audio
PCI Slot x3 Supports PCI expansion cards
PCI Express Gen2 x16 Slot x1 Supports PCI-E Gen2 x16 expansion cards Slots
PCI Express Gen2 x1 Slot x2 Supports PCI-E Gen2 x1 expansion cards
