2.3 INSTALLING SYSTEM MEMORY
A. DDR3 Modules
DDR 3_A1 DB1DR 3_ DA2DR 3_ DB2DR 3_
1. Unlock a DIMM slot by pressing the retaining clips outward. Align a
DIMM on the slot such that the notch on the DIMM matches the
break on the Slot.
2. Insert the DIMM vertically and firmly into the slot until the retaining
chip snap back in place and the DIMM is properly seated.
