Biostar TA990FXE Setup Manual

TA990FXE
5
CHAPTER 2: HARDWARE INSTALLATION
2.1 I
NSTALLING CENTRAL PROCESSING UNIT (CPU)
Step 1: Pull the lever toward direction A from the socket and then raise the
lever up to a 90-degree angle.
Step 2: Look for the white triangle on socket, and the gold triangle on
CPU should point towards this white triangle. The CPU will fit only
in the correct orientation.

Biostar TA990FXE Specifications

General

Brand	Biostar
Model	TA990FXE
Category	Motherboard
Language	English
