Biral AX 13-1 User Manual

31
english
10. Accessories
3 Standard (included in the scope of delivery)
l Available as an option
– not available
Ball valve
1” external thread
with union nut,
1
1
/
4
” internal thread
Height, 53 mm
Non-return valve
(flow-check valve)
1” external thread
with union nut,
1
1
/
4
” internal thread
Height, 40 mm
Opening pressure:
20–35 mbar
961194_00
B
B
1
T1
T
H
10.1 Heat insulation
for average temperatures of 15 °C to 110 °C
Fire protection category. B2 according to DIN 4102
Type B B1 H T T1
WD1 140 70 140 90 50
10.2 Shut-off set
consisting of non-return valve and ball valve
G 1"
G 1 1/4"
40
961395_00
G 1"
G 1"
961397_00
AXW 12: 217 mm, AXW 13: 247 mm
G 1"
G 1 1/4"
53
961396_00
961394_00
AX 12 AX 10-1 AX 10 AX 12-1 AX 12-2 AX 12-3 AX 12-4 AX 13 AX 13-1 AX 13-2 AX 13-3 AXW 10 AX 13-4 AXW 12 AXW 12-1 AXW 13 AXW 13-1
Other
details,
see
chapter
Heat insulation ll333 ––333 ––––l – l 10.1
Shut-off se –––––––––– ––3 – 3 – 10.2
