CAUTION: Do not proceed with
rim installation without these spacers
12) Rim Spacers Assembly
Prior to installing the rim on to the backboard assembly, insert (4) Plastic and
Steel Rim Spacers (W) into four holes in the backboard. This is very important to
prevent backboard breakage.
13) Rim Assembly
Mount the Breakaway Rim (II) to the Backboard Assembly (D) using the hardware
supplied in the rim box (CC, DD, EE).
