ASSEMBLY
MAIN ASSEMBLY
These instructions illustrate the sequence of
assembling the parts of the rear blade.
We suggest you follow this sequence carefully. The
rear blade assembly must be made with at least two
people and the right equipment to facilitate
assembly.
The following tools are required for assembly the
rear blade:
Rubber hammer.
Bronze hammer.
Wooden blocks.
Flathead screwdriver 5/16" x 8"
Ratchet 1/2"
2 Adjustable wrenches 12”
1 Adjustable wrench 6”
or
2 Combination wrench 1 1/8"
2 Combination wrench 1"
2 Combination wrench 15/16"
2 Combination wrench 3/4"
2 Combination wrench 9/16"
1 Combination wrench or since 7/16".
In some cases, it is necessary to use a steel mallet
when you install the pins. In these cases, it is
suggested that a piece of wood is used to soften the
impact between the pin and a hammer to avoid
damaging the bolt.
NOTICE
BLADE FALLING DANGER
It could cause serious injury or even death. Keep
hands and feet away from the blade while it is
activated.
NOTICE
CONTUSIONS DANGER
Beware pieced together by pins as they tend to turn.
