BITMAIN AntMiner D3

- 13 -
AntMinerD3InstallationGuide
5. Monitoring Your Miner
5. Monitoring Your Miner
To check the operating status of your miner:
1. Click Miner Status.
2. Under AntMiner, monitor your miner according to the descriptions in the following table:
Option
Description
ASIC#
Number of chips detected in the chain.
Frequency
ASIC frequency setting.
GH/S(RT)
Hash rate of each hash board ( GH/s)
Temp(PCB)
Temperature of each hash board (°C).(Applied only to miner with fixed frequency)
Temp(Chip)
Temperature of the chips on each hash board (°C).
ASIC status
One of the following statuses will appear:
● O - indicates OK
● X - indicates error
● - - indicates dead
6. Administering Your Miner
Note: The D3 miner will stop running when the Temp(PCB) exceeds to
85°C, there will be an error
message “Fatal Error: Temperature is too high!” shown in the bottom of kernel log page.
