Bitzer 2KTE - Shut-Off Valves; Connections

KB-130-76
4.2 Shut-off valves / connections
High-pressure side Shut-off valve
article No.
Connection type Inner dia-
meter
Outer dia-
meter
Characteristic
value
Compressor mm mm
2MTE..2KTE 36136718 Brazed/welded 19.15 25.4 76
36136719 Compression fitting 18 126
36136720 Brazed/welded 10 14 128
36136721 Brazed/welded 16.1 22 127
36136723 Brazed/welded 22.35 30 153
4PTC .. 4KTC
4PTE .. 4KTE
4PTEU .. 4KTEU
36136718 Brazed/welded 19.15 25.4 76
36136719 Compression fitting 18 126
36136720 Brazed/welded 10 14 128
36136721 Brazed/welded 16.1 22 127
36136723 Brazed/welded 22.35 30 153
36136726 Brazed/welded (with 2
service connections)
19.15 25.4 160
4JTC..4CTC
4JTE .. 4CTE
4JTEU .. 4CTEU
36136718 Brazed/welded 19.15 25.4 76
36136719 Compression fitting 18 126
36136721 Brazed/welded 16.1 22 127
36136723 Brazed/welded 22.35 30 153
6FTE..6CTE
6FTEU .. 6CTEU
36136724 Brazed/welded 28 35 152
36136727 Brazed/welded (with 2
service connections)
28 35 161
Tab.3: Shut-off valves and connection sizes, high-pressure side
Low-pressure side Shut-off valve
article No.
Connection type Inner dia-
meter
Outer dia-
meter
Characteristic
value
Compressor mm mm
2MTE..2KTE 36131550 Brazed/welded 22.35 30 28
4PTC .. 4KTC
4PTE .. 4KTE
4PTEU .. 4KTEU
36131550 Brazed/welded 22.35 30 150
4JTC..4CTC
4JTE .. 4CTE
4JTEU .. 4CTEU
36131554 Brazed/welded 28 35 153
6FTE..6CTE
6FTEU .. 6CTEU
36136725 Brazed/welded 35 42 152
Tab.4: Shut-off valves and connection sizes, low-pressure side
